SAC2 is the solution to improve the contact of your EEG electrodes for long term monitoring and sleep recording. SAC2 provide a fast application and adhesion of the electrodes, the connection is stable for more than 72 hours. It is biocompatible and easy to clean with just a drop of water. Safe for the patient safer for the technologist.
Features
- Fast adhesion to the scalp
- Clean with water
- Safe for the Patient and the Technologist
- Tube is designed for direct application
- Hold the electrode securely in place for sleep and long
term recordings
Application
Prepare the skin with a prep gel. Cut gauze into one inch by one inch squares.
Fill a cup electrode with a conductive paste (AC Cream
conductive paste), just enough to fill the cup.
Squeeze a bit of cream (SAC2 electrode cream) on a piece
of gauze to hold the electrode down for about 10 seconds,
which dries up fast. This method does not actually “mix”
conductors, since there is almost no contact between the
two. One conductor is inside the electrode cup and the
other one is on the outside and not serving any conducting
function. The electrode impedance should be less than
5,000 Ohms and balanced.
After the impedances are found to be satisfactory, apply a
piece of tape over the electrodes on the forehead and the
temples, e.g., F7. Fp1, Fp2, F8, T1, and T2. Now you are
ready to wrap the head.
Two 4 inch self-adhering, conforming bandages are used.
Tape the head wrap for security and then place a net over
the head, which is very convenient, especially for children.
